11 motor manual glass beveler with digital speed easy operation

This machine is designed for producing bevel edge, with bottom edge grinding. The conveyors use short-joint big roller chain system. Grinding wheel are directly driven by high precision ABB motor. The working speed is adjustable by stepless regulator. The front rail is driven by motor for adapting to various glass thickness. The glass thickness and working speed are shown on digital readout. This machine is featured by high efficiency and precision, stable quality, easy operation and low wear.

Compare

Add to wishlist

Categories: Glass Beveling Machine, ZX371A, ZXM

Description
Reviews (0)

Description

ZX371A

Chain & bearing combined conveyor system

High quality and precision ABB motors

Machine Introduction

This machine is designed for producing bevel edge, with bottom edge grinding. The conveyors pads use reinforced steel sheets, which are treated under special process and have high rigidity. The glass transmittance is very smooth. spindles are directly driven by high precision ABB motor. The working speed is adjustable by stepless regulator. The glass thickness and working speed are shown on digital readout. This machine is featured by high efficiency and precision easy operation and low cost.

back pads washing unit

Technical parameters

Item	Parameter	Range
1	Working speed：	0.5-4m/min
2	Min glass size：	80mm×80mm
3	Glass thickness：	4mm-15mm
4	Max． bevel width：	50mm
5	Bevel angle：	0°~25°
6	Total power：	22.5kW
7	Base Dimension：	7.6×1.2×2.6m
